Model：

GA-1201-EU

Power:

12W max.

Input：

100-240VAC   50/60Hz

Output Voltage:

12V

Output Current:

0.1-1A

Input current:

0.3A max.

Inrush Current:

1.2 Amps max. at   230VAC/50Hz,full load

Leakage Current:

1.2mA Max. at   264VAC input

Energy   Efficiency Level VI :

CoC 5 / DoE 6 /   CEC VI

Protections：

Short Circuit   /Over Current /Over Voltage

Short Circuit   Protection (SCP)：

Protection to   Zero Voltage

Over Voltage   Protection (OVP):

≤Vout*150%

Over Current   Protection (OCP):

110%-180%

Working TEMP.:

-20°C-50°C

Working Humidity：

5%-90% RH   non-condensing

Storage   TEMP.,Humidity and altitude:

-40℃ ~+70°C ambient temperature and a 5% to   95% relative humidity range throughout an altitude range of -60 meters to   +5000 meters AMSL.

Input Plug:

US 2pin

Certificates and   approvals:

CE,EMC,

EMI EMISSION:

Radiation   Test&Conduction Test: EN 55022/FCC Part 15
  Harmonic Test : EN 61000-3-2
  Flicker Test : EN 61000-3-3

EMS IMMUNITY:

ESD   Test:EN 61000-4-2
  RS    Test:EN 61000-4-3
  EFT   Test:EN 61000-4-4
  Surge Test:EN 61000-4-5
  CS     Test:EN 61000-4-6
  MF     Test:EN 61000-4-8
  DIP    Test:EN 61000-4-11

MTBF:

100000 hours   minimum at full load at 25℃ ambient
